Edit Low Voltage Device Schedule List

To edit low voltage device schedule project settings, go to
Ribbon: DME: Customization→Project Customization→ Low Voltage Device Schedule Label Group icon Low Voltage Device Schedule Label Group
Pulldown Menu: DM Electrical→Customization→Labels and Schedules→Project List→Edit Low Voltage Device Schedule Project List

To edit low voltage device schedule standards settings, go to
Ribbon: DME: Customization→Master & Standards Customization→ Low Voltage Device Schedule Label Group icon Low Voltage Device Schedule Label Group
Pulldown Menu: DM Electrical→Customization→Labels and Schedules→Standards and Master Lists→Edit Low Voltage Device Schedule Master List

Select Low Voltage Device Group Dialog Box​

Low voltage devices select low voltage device group dialog box

Select the low voltage device group to be edited and press the button.

<Low Voltage Device Group> Schedule Label Display and Order Dialog Box​

Customization low voltage device schedule label display and order dialog box

Visit the Common Label and Schedule Information section for more information about using the and buttons and the Key ☰, Label, Width, Justification ▾, and ☐ Display fields.

Values in the Key ☰ column are listed alphabetically below.

  •  Callout The callout of the low voltage device as defined in the low voltage device project schedule.

  •  Quantity The number of low voltage devices inserted in the project. If a low voltage device type is not inserted, NOT USED will be displayed.

  •  Schedule Note 1 Note taken from the schedule.

  •  Schedule Note 2 Note taken from the schedule.

  •  Schedule Note 3 Note taken from the schedule.

  •  Symbol The block used to represent the low voltage device.
